Single Fiber Dual Mode WiFi Router XPON ONU With TV Port

Model NO: JZ9327B-GWSC

XPON ONU With TV Port Brief Introduction:

* 1GE3FE WiFi TV ONU JZ9327B-GWSC is compliant with standard OMCI definition;

* JZ9327B-GWSC GPON ONT is manageable at remote side;

* And supports the full range FCAPS functions including supervision, monitoring and maintenance;

* JZ9327B-GWSC ONT supports CATV module;

XPON ONU With TV Port Features:

* Flexible mapping between GEM Ports and T-CONT

* Activation with automatic discovered SN and password in conformance with ITU-T G.984.3

* AES-128 Decryption with key generation and switching

* FEC (Forward Error Correction) in both directions

* DBA reporting by piggyback reports in the DBRu (mode 0 and mode 1)

* Mapping of GEM Ports into a T-CONT with priority queues based scheduling

* Support Multicast GEM port and incidental broadcast GEM port.

Technical Parameters of XPON ONU With TV Port:

Items	Unit	Parameters
Working wavelength:	nm	PON:TX1310,RX1490;CATV:1150～1600
Optical connector:		SC/APC
CATV optical power range:	nm	+2～-18nm
RF output level:	dBuv	≥75
CNR/MER:	dB	≥45/32
Power supply:	V	AV110～255V→DC12V 1A
Working Environment	℃	-5℃ ~ 45℃

     Jizhong Technology is high-tech enterprise which integrated R&D,manufacture,sales,service.The enterprise under XI’AN Jizhong Intelligent Technology Co.,Ltd. and Shaanxi Jizhong Electronics Technology Co.,Ltd.Jizhong has a group professional R&D staff dedicated to optical fiber communication,data communication,home gateway,intelligent terminal and intelligent internet of things system for many years.It was identified as city-level technology centers, technology innovation demonstration enterprises in Nov.,2015.Xi’an Jizhong Intelligent Technology Co.,Ltd in January 2016, listed on the National Equities Exchange and Quotation”New Three Board”success. stock code: 835316.
     Products covers FTTH network transmission products and solutions, home intelligent gateway, DVB + OTT/IPTV intelligent terminal, home intelligent terminal products and integration solutions, smart home system and full range of communication control unit products, the fiber optic communications, data communications and video end-to-end network equipment and the overall solution.
